Clicking the REVOLITE logo will download the "REVOLITE EDITOR" application software
to create data reserved for the REVOLITE.
EDITOR for REVOLITE_Ver1.05_en
Clicking the download button will download the sample pattern data (.dts) files shown in the videos.
Choose a favorite pattern from the data samples made at our company, and load it into the LA6 REVOLITE.
Furthermore, based on the downloaded sample data, it is possible for you to customize the luminescence colors, timing, buzzer sounds, etc.
[Directions for using the REVOLITE Editor]
①Operate the REVOLITE EDITOR in the time trigger mode.
②Import the downloaded data into the REVOLITE EDITOR application software by selecting "Import" from the file menu at the upper left of the screen.
③Click the "Send to Product" icon at the bottom of the screen in the REVOLITE EDITOR application software.
* For further details on the REVOLITE EDITOR application software, refer to the help files within the program.
[Hardware Requirements]
Click HERE to confirm your hardware requirements before starting any downloads.
1. "Diverse Luminescence Color" with an implementation of sensor information to display temperature,
water levels, etc., can show a detailed operation status
for equipment in an easy visualization environment.
Tiers: 5 tiers
Smart Mode Type: Time-trigger Type
2. "Level Meter Display" for process management can show remaining
time with representation of a color bar, enhancing time management.
Tiers: 5 tiers
Smart Mode Type: Time-trigger Type
3. "All-point Lighting Display" can improve
the information visibility from a distance.
Tiers: 5 tiers
Smart Mode Type: Time-trigger Type
4. "Level Meter Display" can show remaining time of machinery operation,
and display the lapsed time when it is stopped during its maintenance downtime.
Tiers: 5 tiers
Smart Mode Type: Time-trigger Type
5. "Level Meter Display" can visibly show the status of progress to a process.
Tiers: 5 tiers
Smart Mode Type: Time-trigger Type
6. "Sine-wave Display" can utilize distance to distinguish visibility in a new mode of expressing a status condition
which is indicating a machine on standby.
Tiers: 5 tiers
Smart Mode Type: Time-trigger Type
7. "Timer Display" can be used to manage question- and-answer time to efficiently complete a meeting by displaying various announcements with the
diverse operational modes.
Tiers: 5 tiers
Smart Mode Type: Time-trigger Type
8. "Cycle-time Display" on a factory line can signal elapsed cycle
time that can lead to indicating equipment maintenance is necessary.
Tiers: 5 tiers
Smart Mode Type: Time-trigger Type
9. "Sine-wave Display" can utilize distance to distinguish visibility in a new mode of expressing a status condition which is useful in
indicating a machine has completed a task.
Tiers: 5 tiers
Smart Mode Type: Time-trigger Type
10. "Level Meter Display" can visibly show the status of remaining material
in a parts bin to decrease machinery waiting time for refills.
