· 32 sounds are pre-recorded in one unit.
· For enhanced durability and safety in the work environment.
· Built-in Alarm: Adjustable audible sound up to 105dB at 1m with volume control.
· Installation: Indoors—upright, inverted, sideways; Outdoors—upright only. (Do not install the horn facing upward).
※PATLITE Corporation has not applied for permission to use certain copyrighted music or songs recorded in RT-A, C and D types outside of Japan. For additional information regarding this issue, please contact your local PATLITE sales representative.
|DIMENSIONS||- 162mm diameter|
|OPERATING VOLTAGES||- 24V DC
- 100V AC
- 200V AC
|AUDIBLE STYLE||- RT-A/C/D/E: 32 pre-recorded alarm sounds|
|SOUND RECORDING OPTIONS||- Messages composed from a pre-recorded library (Message availability may be limited)
- Customized Messages can be created at the factory (Additional costs may apply)
|SOUND SELECTION||- High-quality digital recording|
|VOLUME||- Maximum 105dB at 1 meter with adjustable volume control|
|BODY STYLE||- Red
|BODY COLOR||- Acrylic Resin|
|STACKABLE TIERS||- Dry contact closure such as switches or relay contacts
- Open-collector transistor (NPN for DC24V and AC120V)
- Direct voltage control for DC24V, K and L-type Units only (see wiring diagrams)
|PROTECTION RATING||- CE (Only 24V DC)
- IP-23 (IP-65 and UL by special order)
